Aorun LED/PCB Electronic Potting Silicone Glue Double Component Adhesive
Quick Detail:
| Name |
Epoxy Resin AR89 |
Usage |
Electronic |
|
Mixing Ratio |
A: B =1:1 (By weight) | Advantages |
Fine flexibility,good abrasion strength,good yellowing resistance,light color and Low VOC,Chemical resistance |
AR89 potting and encapsulating compounds consists of epoxies and silicones systems. Our products feature outstanding electrical insulation properties, superior adhesive strength, thermal conductivity and excellent chemical resistance. AR89 potting and encapsulating compounds provide reliable long term performance for microelectronic, electronic, electrical devices.
Range of applications:
1. The utility model can be used for sealing, packaging, insulation and moisture-proof electronic or other products;
2. Widely used in transformers, AC capacitors, high pressure packs, negative ion generators, aquarium pumps, ignition coils, power modules, electronic controllers and other electronic components;
3. Not suitable for flexible or soft shell products.
Application:
1. Automotive electronics module
2. Power control module
3. Solar panels junction box LED screen
4. LED wall washer, LED module, etc
| Items | Units/conditions |
Technical Data
|
| Viscosity | Shore-D | 80-85 |
| Volume resistivity | 25℃/ Ω./ cm | 4.3x1015 |
| Surface resistivity | 25℃/ Ω. | 2.6x1014 |
| Dielectric strength | 25℃ KV/MM | 25 |
| Coefficient of linear expansion | CM/K | <6.1x10-5 |
| Glass transition temperature | ℃ | >90 |
| Temperature resistant | ℃ | -60~120 |
Our services:
1. Professional R&D team
2. One-stop service for thermal conductive material
3. Support customized orders,including size,shape,color, and thermal conductivity or can be coated one side or two sides adhesive or fiberglass according to your demands
4. Free sample provided
5. Manufacturer offers best price
6. Good quality and fast delivery
7. Professional after-sale servic
8. Prompt response within 24 hours
FAQ:
1.How about sample policy?
If we have the sample in stock .we will provide free sample to u. if we don't have in stock . then u should pay the sample fee . any way . the sample fee will pay back to u. when u confirm the order
Sample fee is charged by the shippign company . Client should pay it :)
2.Which shipping way is available and how to track?
By sea to your nearest port
By express (DHL,UPS,FEDEX,TNT,EMS)to your door
When ur order shipping out . we will provide u a tracking no. then u can know clearly the status of the goods
3:My package has missing products. What do I do?
A: Please contact our support team and we will confirm your order with the package contents. We apologize for any inconveniences!
4.Which payment way is workable?
Western Union,L/C,Paypel
T/T (30%deposit, 70% before shipment after presentation of ready cargo)
